"Slope gradients are written as Y:X, where Y is a single unit in rise and X is the run. Both numbers must use the same units. For instance, if you travel 3 inches vertically and 3 feet (36 inches) horizontally, the slope would be 3:36 or 1:12. This is read as a "one in twelve slope."

Slope percentage is calculated in much the same way as the gradient. Convert the rise and run to the same units and then divide the rise by the run. Multiply this number by 100 and you have the percentage slope. For instance, 3" rise divided by 36" run = .083 x 100 = an 8.3% slope.
